※Adopt imported high quality steel,high strength, good rigdity
※Sealed batteries free of maintenance. safe operation and no pollution;
※Explosion-prood valve design, down more stable san relaible;
※over discharge protection, extending battery life.
Specification
Model
sDYG-Z0511
capacity
Q(Kg)
500
Load center
c(mm)
400
Type of lifting
电动Electric
operating type
步行Walkie
Material
尼龙/聚氨酯Nylon/PU
wheel base
y(mm)
860
Front wheel base
b11(mm)
380
Back wheel base
b10(mm)
670
Quantity of Steering/Bearing/Balance wheel
2/2/6
Bearing wheel size
mm
φ70×60
Steering wheel size
mm
φ100x50
Balance wheel size
mm
φ40×26
Training wheel size
mm
φ30×26
Min.fork height
mm
90
Max.fork height
h3(mm)
1100
Fork outside width
mm
535
Fork inside width
mm
225
Fork length
l(mm)
1150
single fork size
e/s(mm)
155/60
overall length
L1(mm)
1600
overall width
b1(mm)
790
Overall height
h1(mm)
1400
whole height(after tape file shelf)
h4(mm)
2500
Length of vertical surface to fork
l2(mm)
1150
Min.turning radius
wa(mm)
1100
Lifting speed(laden/unladen)
mm/s
80/110
Lowering speed(laden/unladen)
mm/s
80/80
Lift motor
Kw
12V0.8
Battery capacity
v/Ah
12/33
Battery weight
Kg
10
Net weight
Kg
197
Packing & Delivery
Packaging Details:wooden package Delivery Detail:Shipped in 20 days after payment
Certifications
Ralated products
FAQ
1. What's your Price Terms? A: We offer FOB ,FCA, CIF, CFR and DDU price terms. 2. Can i place mix order?For example, i need 1 pc Electric Stacker and 1 pc Hand Pallet Truck,can this ok? A: Yes, of course. You can mix different models as you wish. 3. Can you send the machine to my factory in other city to load the container? A: Yes, please tell us the detail address, we can arrange to send your factory in time. 4. Are the forklift trucks covered by a warranty? A: Yes. All our machines carry a full 1 year major parts warranty. 5. Can i get discounts? A: Yes, For big order, old customer and frequent customers, we give reasonable discounts. 6. How to place an order? A:Tell us your detail requirements(Load Capacity? Lifting height etc.) by email or on Trademanager or Whatsapp ,We will send you our offer in 24 hours. If ok, please send us your purchase order, or you can ask us to send you a proforma invoice for your order. 7. How long could i get my order? produce 1~5 pcs, delivery time is 20days; produce 6~12 pcs, delivery time is 25 days. 8. Can you add our own logo on the products or use our designs? A: Yes,of course you can add logo on our products! We provide OEM/ODM service.In addition, we promise your design would protect by law, we won't tell anyone else about this. It's your own copyright.
