| EPM80: | |
|---|---|
| Quantity: | |
| Sr.No | Model or data | Memo | ||||||
| 1 | Main cylinder | Model no | YG250/180 | Quantity | 1 | | ||
| Norminal pressurer | 1250KN | Stroke | 4500mm | |||||
| 2 | Close door cylinder | Model no | YG110/75 | Quantity | 1 | | ||
| Norminal pressurer | 237KN | Stroke | 62mm | |||||
| 3 | open door cylinder | Model no | YG110/75 | Quantity | 1 | |||
| Norminal pressurer | 237KN | Stroke | 730mm | |||||
| 4 | Material box size (L*W*H) | 4200*1100*1100mm | | |||||
| 5 | Compression chamber size (L*W*H) | 2000*1100*1100mm | | |||||
| 6 | Feeding mouth size (L*W) | 2000*1100mm | | |||||
| 7 | Bale size (L*W*H) | 1120*1100*1100mm | Final coconut fiber block size | |||||
| 8 | Hydraulic system working pressure | 25Mpa | | |||||
| 9 | bale size | 450kg(450~480kg/m³) | | |||||
| 10 | Voltage/Frequency | 380V/50HZ | | |||||
| 11 | Motor power | 30KW | | |||||
| 12 | Main motor | Model No. | Y250M-6 | Quantity | 1 | | ||
| Power | 37Kw | Rated speed | 980r/min | |||||
| 13 | Piston pump | Model No. | 250YCY15-1B | Quantity | 1 | | ||
| Outpou volumn | 250ml/r | Rated pressure | 31.5Mpa | |||||
| 14 | Piston pump | Model No. | 40YCY15-1B | Quantity | 1 | | ||
| Output volumn | 250ml/r | Rated pressure | 31.5Mpa | |||||
| 16 | Single cycle time | 70S | | |||||
| 17 | Capacity | 2-4T/h | | |||||
| 18 | Bundle lines | 5，manual bundle | | |||||
| Sr.No | Model or data | Memo | ||||||
| 1 | Main cylinder | Model no | YG250/180 | Quantity | 1 | | ||
| Norminal pressurer | 1250KN | Stroke | 4500mm | |||||
| 2 | Close door cylinder | Model no | YG110/75 | Quantity | 1 | | ||
| Norminal pressurer | 237KN | Stroke | 62mm | |||||
| 3 | open door cylinder | Model no | YG110/75 | Quantity | 1 | |||
| Norminal pressurer | 237KN | Stroke | 730mm | |||||
| 4 | Material box size (L*W*H) | 4200*1100*1100mm | | |||||
| 5 | Compression chamber size (L*W*H) | 2000*1100*1100mm | | |||||
| 6 | Feeding mouth size (L*W) | 2000*1100mm | | |||||
| 7 | Bale size (L*W*H) | 1120*1100*1100mm | Final coconut fiber block size | |||||
| 8 | Hydraulic system working pressure | 25Mpa | | |||||
| 9 | bale size | 450kg(450~480kg/m³) | | |||||
| 10 | Voltage/Frequency | 380V/50HZ | | |||||
| 11 | Motor power | 30KW | | |||||
| 12 | Main motor | Model No. | Y250M-6 | Quantity | 1 | | ||
| Power | 37Kw | Rated speed | 980r/min | |||||
| 13 | Piston pump | Model No. | 250YCY15-1B | Quantity | 1 | | ||
| Outpou volumn | 250ml/r | Rated pressure | 31.5Mpa | |||||
| 14 | Piston pump | Model No. | 40YCY15-1B | Quantity | 1 | | ||
| Output volumn | 250ml/r | Rated pressure | 31.5Mpa | |||||
| 16 | Single cycle time | 70S | | |||||
| 17 | Capacity | 2-4T/h | | |||||
| 18 | Bundle lines | 5，manual bundle | | |||||
