| Quantity: | |
|---|---|
| Sr.no | Type name | UNIT | Model or parameters |
| 1 | Nominal pressure | KN | 630 |
| 2 | Inner diameter of MAIN DYLINDER | mm | φ180 |
| 3 | The piston roddiameter | mm | φ120 |
| 4 | Stroke | mm | 1200 |
| 5 | Block out cylinder pressure | KN | 100 |
| 6 | Block out cylinder inner diameter | mm | φ80 |
| 7 | The piston roddiameter | mm | φ45 |
| 8 | Block out cylinderstroke | mm | 770 |
| 9 | Pressing Head size | mm | 1062*760 |
| 10 | material box size | mm | 1066×762×1600 |
| 11 | Final block size | mm | 1066×762×400-800 |
| 12 | Motor model | Y132M-4 | |
| 13 | motor power | KW | 7.5KW(3PH,415V/50Hz) |
| 14 | Oil pump model | 40YCY14-1B | |
| 15 | The system maximumpressure | Mpa | 20 |
| 16 | Max distance from pressing head to working table | mm | 1600 |
| 17 | Mode of operation | Manual reversing valve operation | |
| 18 | Strapping way | Manual bundle | |
| 19 | line | pcs | 6 |
| 20 | Machine structure | | Frame structure |
| 21 | Bale out way | | Push bale |
| 22 | Machine overall dimension | mm | 1800*1950*3900 |
| 23 | Oil tank capacity | | 300L |
| 24 | Loading | | 1*20GP |
