| Sr.no | type name | UNIT | Model or parameters | |
| 1 | The container size | feet | 20 | |
| 2 | Turn over Angle | degrees | 0~90 | |
| 3 | Loading capacity | T | 30 | |
| 4 | Box support force | KN | 1270 | |
| 5 | Box pull back force | KN | 700 | |
| 6 | Turn over cylinder 2pcs | mm | The cylinder diameter | Φ180 |
| The piston rod diameter | Φ120 | |||
| stroke | 1800 | |||
| 7 | The system maximum pressure | Mpa | 25 | |
| 8 | motor | Y160M-4 15KW | ||
| 9 | Oil pump | 63MCY14-1B | ||
| 10 | Platform height | mm | 1150 | |
| 11 | Loading height | mm | ≈7000 | |
| 12 | Connection fastening | Angle lock (manual)×4 | ||
| 13 | Operation form | PL Program controlled automatic/manual (remote control)/manual | ||
| 14 | Main machine overall size | mm | 8500×3600×2800mm | |
| 15 | Tank volume | | 400L | |
| 16 | Loading | | 1*40FR | |
