CPD15S
Newvision
| Quantity: | |
|---|---|
| Feature | ||
| Model | Unit | CPD15S |
| Type | | Counterbalanced |
| Load Capacity | kg | 1500 |
| Load center | mm | 500 |
| Front overhang | mm | 390 |
| Wheel distance | mm | 1250 |
| Front track | mm | 915 |
| Rear track | mm | 212 |
| Wheel | ||
| Wheel type | | Soild tyre |
| Front tyre | | 18x5-8 |
| Rear tyre | | 15x4.5-8 |
| Dimension | ||
| Angle of inclination | α°/β° | 3°/6.5° |
| Min. Height of the door frame | mm | 2150 |
| Lifting height | mm | 3000 |
| The lifting height of the whole (after tape file shelf) | mm | 3970 |
| Overhead guard height | mm | 2000 |
| Height from seat to overhead guard | mm | 920 |
| Traction hook height | mm | 425 |
| Overall length | mm | 2820 |
| Min. Right angle channel width | | 1850 |
| Overall width | | 1050 |
| Fork size | mm | 40x100x920 |
| Ground clearance | mm | 90 |
| Min. Ground clearance | mm | 95 |
| Min. Turning radius | mm | 1550 |
| Performance | ||
| Before the bridge, after load,laden/unladen | kg | 3780/650,1340/1570 |
| Travel speed, laden/unladen | km/h | 10/12 |
| Lift speed,laden/unladen | mm/s | 120-130/150-160 |
| Lowering speed,laden/unladen | mm/s | 300/183 |
| Gradeability,laden/unladen | % | 8/10 |
| Electrical configuration | ||
| Drive motor | kw | 6 |
| Lift motor | kw | 3 |
| Steering motor | kw | 0.75 |
| Battery | V/Ah | 48V/360 |
| Brake | | hydraulic |
| Controller | | CURTIS |
| Weight | ||
| Battery weight | kg | 610 |
| Service weight with battery | kg | 2800 |
